Product Overview:
Introducing the Vision SP12-200A 12V 200Ah Lithium Iron Phosphate (LiFePO4) Deep Cycle Battery. Engineered by Vision Technology, this battery is designed to provide safe and efficient power solutions for UPS and energy storage systems. With a long cycle life and excellent performance, it is the ideal choice for those seeking reliable energy storage.
Specifications:
- Rated Voltage: 12.8V
- Rated Capacity: 200Ah
- Cell: 3.2V200Ah
- Rated Energy: 2.56kWh
- Dimensions: 522mm (L) x 238mm (W) x 223mm (H)
- Weight: Approx. 21.5kg
- Terminal Type: M8
- IP Grade: IP65
- Cell Type: Prismatic LiFePO4
Performance:
- Maximum Charge Current: 50A
- Maximum Discharge Current: 100A
- Life Cycle (@25°C, 0.5C/0.5C, 20%DOD): Approx. 9000 cycles
- Life Cycle (@25°C, 0.5C/0.5C, 50%DOD): Approx. 4000 cycles
- Life Cycle (@25°C, 0.5C/0.5C, 80%DOD): Approx. 2500 cycles
- Life Cycle (@25°C, 0.5C/0.5C, 100%DOD): Approx. 1400 cycles
Recommended Parameters:
- Recommended Discharge Voltage: 11.2V
- Recommended Charge Voltage: 13.6 – 13.8V
- Charge Mode: Constant Current/Constant Voltage (CC/CV)
- Maximum Charge Voltage: 14.4V – 14.6V
- Overcharge Protection Voltage: 14.8V – 15.2V
- Discharge Cut-off Voltage Range: 9.2V – 11.2V
Key Features:
- Advanced LiFePO4 Technology: Ensures safety and efficiency
- Long Cycle Life: Up to 9000 cycles at 20% depth of discharge (DOD)
- High Performance: Suitable for UPS, energy storage, and other high-demand applications
- Durable Design: IP65 rated for protection against dust and water
- Maintenance-Free: Trouble-free operation with advanced Battery Management System (BMS)
Applications:
- Ideal For: UPS systems, energy storage, marine applications, RVs, solar systems, and more
- Versatile Use: Suitable for both deep cycle and high power applications
Shipping and Availability:
- Order: Special order item, available for online purchase only
- Delivery: Shipping details available upon request
Why Choose Vision Technology?
Vision Technology is renowned for providing safe and high-quality LiFePO4 battery solutions. The SP12-200A model offers robust performance, long life cycles, and reliable power, making it a top choice for various energy storage needs.
Contact:
For full details and to place an order, please contact us.
