Description
The ideal solution for protecting expensive deep cycle batteries from over-discharge. Automatically disconnects the load when the LVD detects the voltage has dropped to the disconnection point, ideal for 4WDs, camper trailers and smaller caravan applications.
FEATURES Battery protection Prevents damaging the battery through over-discharge
Adjustable disconnect point Set the disconnect voltage to best suit the application
L.E.D status indicator Multi-colour L.E.D indicates connection status of LVD
Vibration and weather proof Potted electronics prevent dust and water ingress (IP65)
Compact size Robust mounting points and compact size permit easy fitment
SPECIFICATIONS
INPUT VOLTAGE: 10–16V
OUTPUT CURRENT: 30A
CONTROL TYPE: MOSFET
DISCONNECT VOLTAGE SETPOINTS: 10.0V, 10.5V, 11.0V, 12.0V
CUT-OUT DELAY: 1 minute
RECONNECT VOLTAGE: 13.0V
FUSE PROTECTED: 30A (1 x 30A)
REVERSE POLARITY: Built-in
THERMAL CUTOUT: 65°C
ENVIRONMENTAL PROTECTION: P65
CURRENT DRAW: 10mA
