NARVA 71989 90mm LED Low Beam Headlamp Assembly – 9–33V with DRL & Position Light

Description

Special order item (online purchase only).

NARVA 71989, Delivering superior performance and visibility, this premium low beam headlamp is ideal for OE fitment to modern trucks and buses. Including a built-in daytime running/position light for unique styling and convenience in one lamp

Polycarbonate lens
Die-cast aluminium housing and integrated Deutsch® connection
Fully sealed (IP66)

Technical Information
INPUT VOLTAGE RANGE:    9-33V
CURRENT DRAW    Low Beam: 1.8A at 12V, 0.9A at 24V. DRL: 1.0A at 12V, 0.5A at 24V. Position: 0.1A at 12V, 0.1A at 24V.
LP RATING    IP66
SIZE    Diameter: 90mm

Complete width: 107mm
Lens diameter: 90mm
Thickness (LENGTH): 90mm
