Description
Enerdrive solar panels 40W are 43+VDC open circuit and are well suited to 24V installations (or 48V by series connections of panels)
SP-EN40W-24V
Usually available 24 hours in-store after purchase
Features:
- High Conversion Efficiency
- Positive Tolerance
- High PID Resistant
- Current Sorting Process
- Extended Wind and Snow Load tests
- Withstanding Harsh Environment
-
5-year warranty
Suitable for:
- Recreational vehicles
- Service vehicles
- Maritime applications
- Off-grid systems
Specifications:
- Max Power Pm (W): 40W
- Power Tolerance: 0% ∼ 3%
- Max Power Voltage Vm (V): 35.50
- Max Power Current Im (A): 1.13
- Open Circuit Voltage Voc (V): 43.1
- Short Circuit Current Isc (A): 1.85
- Max System Voltage (VDC): 1000
- Number of Cells: 36 (3 × 12)
- Frame: Anodized aluminium alloy
- Junction Box: IP67 rated
- Dimensions (mm): 567 x 670 x 35
- Weight (kg): 3.9
- Test Conditions: 1000 W/m², AM1.5, 25°C
Enerdrive Pty Ltd has been providing independent power systems to the Australian market since 1996.
