Black Diamond 40-Tooth Lawn Mower Blade – 13HP Compatible Standard Cut

Description

Powerful 10hp 4 Stroke OHV Petrol Engine
Removable Steel Log Table
Heavy Duty Steel 200mm Splitting Wedge
Auto Return Control Valve with Safety Release Function
550cm Maximum Log Length
50mm Tow Coupler
Features and specifications:
Brand: Millers Falls Black Diamond
Model: LS40BD-BS
Engine: Briggs & Stratton 10 horsepower, 4 stroke, OHV, air cooled
Starting: Manual (recoil) start
Hydraulic cylinder size: 127mm (5″) diameter x 493mm (19.4″) stroke
Oil capacity: 10 litres
Gear pump : 2 stage 11GPM
Automatic return control valve
Maximum splitting force: 40 ton
Wedge height: 8” (203mm)
Split and return cycle time: 18 seconds
Maximum log length: 24” (610mm)
Working position: Horizontal and vertical
Wheels and tyres: 16” x 6.5” pneumatic (overall diameter including tyres) with mudguards and rear reflectors
Coupler: 50mm cast steel with safety chains
Maximum recommended towing speed: 72 km/h Not to be towed on public roads
Package dimensions: 173cm x 72cm x 59cm
Package weight: 315kg
