1-Inch Lowered Triple Tree Kit for 2014+ Harley Touring Bikes

Description

OG 2014‑Up Touring Drop 1″ Triple Trees kit — Original Garage Moto

The OG Moto 2014‑Up Touring Drop 1″ Triple Trees kit is a high‑performance front‑end upgrade for Harley‑Davidson Touring models. Engineered to maximize rigidity and handling, this kit features taller fork tube clamping sections and a thicker cross‑section than the stock trees. Lower your fork up to 1″ to raise bike height for improved ground clearance and a more aggressive stance — a great alternative to using +2″ tubes. Works well with 14‑inch shocks.

Fitment: Fits all 2014‑Up Road Glide models with 49mm front‑end. Will not fit 2023+ CVO models equipped with an inverted front‑end. Does not fit Street Glide models due to fairing mount locations.

Features & benefits

• 1″ drop feature for increased ground clearance and a more aggressive stance
• Precision CNC machined 6061‑T6 aluminum construction
• Stem axle & nut machined from 4140 Chromoly steel for superior strength
• Designed to match OEM rake angle and triple tree offset for straightforward installation and optimized handling
• Available in Hard Anodized and Chrome finishes
• Machined OG logo for a clean, factory look
• Uses standard FL bushings — riser bushings are required for this kit and sold separately
• Stainless steel hardware included
• Includes two wire management clamps (one per side) and two brake line management clamps for a tidy install
• Supplied with a lock and key to retain the fork lock feature
• Innovative reversible riser mounting block allows three riser positions: stock, +1″ and +2″ pullback toward the rider ( +1″ adapters sold separately )

Important compatibility note: For 2014–2023 models, if your bike still uses the OEM ignition switch/fork lock you must have the bike flashed with the “keyless CVO feature” at your local shop before beginning installation. Riser bushings are required and sold separately. +1″ adapters are sold separately.

Installation

Download installation instructions (PDF): OG 2014‑Up Touring Drop 1″ Triple Trees kit — Installation Guide (PDF)

Fitment

• Fits all 2014‑Up Road Glide models with 49mm front‑end
• Will not fit 2023+ CVO models equipped with an inverted front‑end
• Does not fit Street Glide models due to fairing mount locations

Manufacturer: Original Garage Moto
